YAG Laser Machines [MEDRIDIAN]
Meridian Medical MR Q is a fully-featured and integrated Nd:YAG laser combined with renowned European precision optics. The high-grade aluminum mono-block laser housing gives a unique solid feeling. The MR Q features a super Gaussian mode laser profile. Its performance and
accuracy provide excellent laser treatments. The MR Q internal power meters monitor the energy delivered to enhance patient safety.
The LED slit lamp offers five steps magnification changer, from 6 × to 40 ×. The MR Q’s laser cavities are tested under severe conditions, demonstrating outstanding performance.
Technical Specification
| Device description | MR Q |
|---|---|
| Laser source | Q-switched, solid state Nd:YAG 1064 nm |
| Pulse duration | 4 ns |
| Pulse setting | 1, 2 or 3 pulses |
| Maximum repetition rate | up to 3 Hz |
| Maximum energy | 32 mJ |
| Treatment spot size | < 10 μm |
| Cone angle | 16° |
| Treatment beam offset range | Electronically controlled offset, anterior: 150 μm, 300 μm; posterior: 0 μm, 100 μm, 200 μm, 300 μm; |
| Aiming beam | Red diode. Dual Beam. 635 nm |
| Magnification | (6 ×; 10 ×; 16 ×; 25 ×; 40 ×) |
| Cooling system | Air cooled |
| Weight | 24 kg / 53 lbs. (Unpacked) |
| Power rating | 100 – 240 VAC, 50 / 60 Hz |
| Power requirements | 100 VA |
